moe lab

MOE

Lab full name
Microwave and Optical Engineering
Research Activities

The research activities of Electromagnetic Fields and Telecommunications Laboratory at Magna Grecia Center in Taranto and of Microwave and Optical Engineering (MOE) Laboratory are performed by the Microwave and Optical Engineering (MOE) group (http://moe-group.poliba.it/). They are pertaining to the following main topics:



MICROWAVE - Design, fabrication and characterization of antennas and microwave devices for aerospace and communication; substrate integrated waveguide devices (SIW); measurement of electromagnetic compatibility, electromagnetic exposure investigation, bio-compatibility. Microwave applicators for thermal ablation medical therapy. Modeling of accelerating cavities for proton linear accelerators (LINAC) for medical proton-therapy.

Lab main microwave facilities:

1. LPKF ProtoLaser U3 for Rapid PCB Prototyping;

2. Anechoic chamber StarLab Antenna Test Station (SL18), 800 MHz to 18 GHz, automated anechoic chamber;

3. LPKF MiniContac RS Electroplating of Through-Holes;

4. LPKF MultiPress S: Press for Producing Multilayers (up to 8 layers);

5. R&S ESU EMI Test ReceiverESU26: standard-compliant EMI test receiver + high-end spectrum analyzer, 20 Hz to 26.5 GHz, full compliance with CISPR 16-1-1 standard;

6. R&S ENV216 LISN two-line V-network for disturbance voltage measurements on single-phase EUTs: 9 kHz - 30 MHz, isolation > 40 dB, max continuous current 16 A, high-pass filter 150 kHz;

7. E.M. field power meter: Narda 8053-2004/40 portable EM fields meter: E-field 100 kHz÷7 GHz, H-field 5 Hz÷400 kHz;

8. Narda Area Monitor System 2600: Remote Monitoring of Electromagnetic Fields; E-field 100 kHz÷7 GHz, H-field 5 Hz÷100 kHz;

9. Near field probes: active broadband probes for EMI diagnosis for frequencies of up to 1 GHz, H-field probe, High-impedance probe, E-field probe;

10. Microwave Network Analyzer Agilent N5224A PNA 10 MHz to 43.5 GHz, 2-ports;

11. Rohde&Schwarz R&S FSH3 handheld Spectrum Analyzer: 100 kHz to 3 GHz, resolution bandwidth 1 Hz, distance to fault measurement option, two-port measurements with tracking generator;

12. Vector Network Analyzer Agilent FieldFox N9917A, 30kHz-18GHz;

13. OscilloscopeTektronik TSD1002, Bandwidth 60 MHz, 2-channel

14. R&S SMB100A RF and Microwave Signal Generator: 100 kHz to 20 GHz, AM, FM and Pulse modulator, Pulse generator, Pulse train;

15. Function generator Instek GFG-8210: 0.1Hz-10MHz;

16. Dielectric probe kit SPEAG for dielectric constant measurement 10MHz-50GHz;

17. Weller soldering station WSD-081;

18. Printer Ink-Jet EcoTank ET-M1170 for flexible circuit printing on Novele IJ-220 coated PET substrate;

19. Antennas: R&S HL050 Antenna: Log-Periodic Directional Antenna for linear polarization: 850 MHz to 26.5 GHz, input impedance 50 W, VSWR≤2.5, gain=8.5 dBi; R&S HF907 Antenna: Double-Ridged Waveguide Horn Antenna: broadband directional antenna for EMC measurements: 0.8 GHz to 18 GHz input impedance 50 W, VSWR≤2.0, gain=5÷14 dBi; R&S HL040 Antenna: Log-periodic broadband antenna: 400 MHz to 3 GHz input impedance 50 W, VSWR≤2.0, gain=5÷7 dBi.



OPTICS - Design, fabrication and characterization of fiber lasers. Modeling of photonic crystal fibers (PCF), for near infrared (NIR) and medium infrared (MID-IR) applications. Modeling of innovative materials and rare earth doped optical devices in optical fiber and in planar optics; nonlinear device modeling; optical microresonators; design, fabrication and characterization of optical devices for environmental monitoring and biomedicine.

Lab main optical facilities:

1. Vytran GPX-2400 Splicer GPX PTR Fiber Optic Glass Processing Unit;

2. Automatic Cleaver Vytran LDC-400;

3. Fiber Optic Recoater PTR-200;

4. Ytterbium fiber Lasers CW 30 W and CW 100 W, with chiller Liekky;

5. Lightwave Component Analyzer HP 8703A 1300 nm/ 130 MHz – 20 GHz;

6. Light Source deuterium-halogen Ocean Optics DH-2000-S DUV: deuterium lamp 210–400 nm; halogen lamp 300–1500 nm;

7. SLED diode, wavelength 1550nm, Output power 15mW (typ.), Bandwidth 45nm (typ.), current 300mA, output Gaussian, package 14-BTF;

8. Nanoplus Mid-IR ICL;

9. Infrared Chamber;

10. EDFA;

11. UV-VIS Ocean Optics spectrometer HR4000;

12. equipped optical benches;

13. Nanoscan M2 beam quality measurement;

14. Farfield Beam Profiler Ophir® Pyrocam IIIHR;

15. Optical spectrum Analyzer 350-1000 nm, resolution up to 1 pm; Fast sweep time; max input level: ± 10 dBm;

16. FBGA interrogator module with USB 2.0 interface, Spectral Range: 1525-1565nm







Department
Contact Person
Technical Staff
Antonio Crudele
Companies and Institutions
district of Manduria (TA), district of Statte (TA), district Volturino (FG), MISE – Bari.
IUT University du Main, L'Institut d'Electronique et des Technologies du numéRique (IETR) Rennes, University of Nice, Università Politecnica delle Marche
MERMEC/SITAEL, SOMACIS, ITEL, OPTEL InP, Dyrecta, Leanfa, EMITECH, SAFRAN.
Università di Rennes1 - Francia; UMR-CNRS - Institut de Physique de Rennes (IPR) – France;
Institut de Recherche en Ingénierie Moléculaire et Matériaux Fonctionnels, UMR CNRS - Le Mans - France; laboratoire de Physique de l'Université de Bourgogne - France;
Physics Dep. Shiraz University, Shiraz - Iran; The Institute for Photonics & Advanced Sensing (IPAS), Centre of Expertise in Photonics (CoEP) University of Adelaide - Australia; University of Tokyo – Giappone;
Mesures Physiques Department- IUT Institut Universitaire de Technologie du Mans – Francia; INFM – Lecce; CNR-FSA – Trento; IROE-CNR - Firenze Politecnico di Milano; Politecnico di Torino;
Dept. of Applied Sciences, Ho Chi Minh City University of Technology and Education, Vietnam; IFN-CNR CSMFO Lab. and FBK Photonics Unit, Povo-Trento, Materials Physics Center CSIC-UPV/EHU San Sebastian, Spain;
Institute of Low Temperature and Structure Research, PAS, Wroclaw, Poland; Swansea University (UK), Nottingham University (UK)
La Verre Fluorè, ATLAS, FYLA, SELENOPTICS, Somacis, Emitech, Neetra, RTM, Quanta System, Centro Laser.
Projects
SIW technologies and devices for ICT applications
Potenziamento delle strutture e delle dotazioni scientifiche e tecnologiche del polo scientifico e tecnologico Magna Grecia" (Sez. Campi e.m
Development of innovative small size systems for radiotherapy ) ”_ AMIDERHA (1.04 Meuro) _
“ERHA, Advanced Radiotherapy with hadrons”
Research activity AR - A.2.1.1 Research Activity Title “Analisys and electromagnetic design of an applicator for thermal ablation” within the project FESR-FSE 2014-2020 “SINACH – Integrated navigation for mini invasive, surgery”
Research activity Task 3.3 Research Activity Title “Fiber optic systems for space application” – 30 months duration, within the project PON “New Satellite Generation Components (NSG)"
Research activities OR3 (A 3.5 e A 3.6) OR2 (A 2.1) of the electromagnetic field group within the MIUR project “Agriculture Green & Digital – AGREED”
Research activities of WP7 Fibre Pigtailing & Combining, of the project H2020 “PASSEPARTOUT Photonic Accurate and Portable Sensor Systems Exploiting Photo-Acoustic and Photo-Thermal Based Spectroscopy for Real-Time Outdoor Air Pollution Monitoring”
“Fast monitoring of aflatoxines in milk” pertaining to the optimization of a portable spectroscopy set up - contract between the DEE - Department of Electrical and Electronic Engineering of Politecnico di Bari and Plurima Software SRL
MIUR PRIN 2022, NRPP – DD n. 1181 del 27-07-2023 - InnoVative tEchnoloGies for non-invasivE assessment of plAnt healTh conditIon to support precisiOn farmiNg “VEGETATION”
European Union under the Italian National Recovery and Resilience Plan (NRRP) of NextGenerationEU, with reference to the partnership on “Telecommunications of the Future” (PE00000001 - program “RESTART”, CUP: D93C22000910001) - STRUCTURAL PROJECT DREAMS
ASI 687/2022 - MUR 341 15/03/22 “SPACE IT UP”
ASI 2024-68-I.0 “Origami Reconfigurable Beam-steering Antennas with METAsurfaces for Communication on Small Satellites - ORBIT-META”
HORIZON TMA MSCA Staff Exchanges (101182995) “Cr4+:YAG/Polymer nanocomposite as alternative materials for Q-switched lasers: properties, modeling, and applications - ALTER-Q”
Facilities
LPKF ProtoLaser U3 for Rapid PCB Prototyping;
StarLab Antenna Test Station (SL18), 800 MHz to 18 GHz, automated anechoic chamber;
LPKF Electroplating of Through-Holes;
LPKF MultiPress S: Press for Producing Multilayers (up to 8 layers);
R&S ESU EMI Test Receiver;
R&S ENV216 two-line V-network for disturbance voltage measurements on single-phase EUTs;
E.M. field power meters; Narda Area Monitor System 2600: Remote Monitoring of Electromagnetic Fields; a number of wide band antennas covering the RF-MW range;
Optical spectrum analyzers Agilent N5224A PNA 10 MHz to 43.5 GHz; Rohde Schwarz FSH3; Agilent FireFox VNA, Microwave Signal Generators;
Dielectric probe kit SPEAG for dielectric constant measurement 10MHz-50GHz; Weller soldering station etc
Splicer GPX PTR Fiber Optic Glass Processing Unit;
PTR PTR Fiber Optic Recoater Fiber Optic Recoater;
Ytterbium fiber Lasers CW 30 W and CW 100 W;
Infrared Chamber;
EDFA
UV-VIS Ocean Optics spectrometers;
equipped optical benches;
Nanoscan M2 beam quality measurement; Optical spectrum Analyzer etc
Softwares
computer codes based on Transfer Matrix Method (TMM), Finite Element Method (FEM), Beam Propagation method (BPM), finite difference time domain (FDTD), Method of Moment (MoM)
CST, COMSOL, BEAMPROP
Services
design of microwave devices and planar antennas for enterprises
planning and optimization of electromagnetic field covering for mobile phone aims and identification of BTS geographical position
measurement of electromagnetic field level at low (50Hz) and high frequency (2-20GHz), control of human exposure to the electromagnetic field
study of biological effects due to the human exposure to the electromagnetic field
Address / How to reach us
Aule ex DIASS; Viale Turismo 8, Taranto
DEI sede storica, 2° piano; Via Orabona 4, BARI
DEI Plesso Salvatore, piano terra; Via Orabona 4, BARI
Hours
9:00-17:00
Area (mq)
100
